SGLang 部署与使用指南

目录

环境准备与安装

基础环境配置

1
2
3
4
5
6
7
8
# 禁用IPv6
sysctl -w net.ipv6.conf.all.disable_ipv6=1
sysctl -w net.ipv6.conf.default.disable_ipv6=1

# 设置网络接口和NCCL参数
export GLOO_SOCKET_IFNAME=eth0
#export NCCL_DEBUG=info
export NCCL_IB_DISABLE=1

Docker容器部署

1
2
3
4
5
6
7
8
docker run -d -t --network=host --gpus all \
    --privileged \
    --ipc=host \
    --cap-add=SYS_PTRACE \
    --name sglang \
    --ulimit memlock=-1 \
    --ulimit stack=67108864 \
    -v /mnt:/mnt registry.cn-hangzhou.aliyuncs.com/lky-deploy/llm:sglang-0.4.2.post2 bash

服务启动配置

https://github.com/sgl-project/sglang/blob/main/benchmark/deepseek_v3/README.md

单节点启动

1
2
3
4
5
6
7
8
9
python3 -m sglang.launch_server \
    --port 40000 \
    --model-path /mnt/DeepSeek-R1 \
    --trust-remote-code \
    --tp 32 \
    --host 0.0.0.0 \
#可选
--enable-torch-compile
--torch-compile-max-bs

双节点分布式启动

节点1 (Rank 0):

1
2
3
4
5
6
7
8
9
10
11
python3 -m sglang.launch_server \
    --port 30000 \
    --model-path /mnt/7B \
    --mem-fraction-static 0.8 \
    --trust-remote-code \
    --tp 16 \
    --dp 2 \
    --enable-dp-attention \
    --dist-init-addr 10.0.1.105:20000 \
    --nnodes 2 \
    --node-rank 0

节点2 (Rank 1):

1
2
# 修改node-rank参数为1，其他配置保持与节点1一致
--node-rank 1

功能测试

1
2
3
4
5
6
7
8
9
curl http://localhost:30000/generate \
 -H "Content-Type: application/json" \
 -d '{
  "text": "deepseek中有几个e？",
  "sampling_params": {
  "max_new_tokens": 3000,
  "temperature": 0
 }
}'

性能基准测试

1
2
3
4
5
6
7
8
9
python -m sglang.bench_serving \
--backend sglang --host 127.0.0.1 --port 30000 \
--model /mnt/DeepSeek-V3/DeepSeek-V3/ \
--dataset-name random \
--random-input-len 20000 \
--random-output-len 4096 \
--max-concurrency 8 \
--num-prompts 80 \
--dataset-path /root/ShareGPT_V3_unfiltered_cleaned_split.json &> 20k_8_80.txt &

PD分离部署

https://docs.sglang.ai/advanced_features/pd_disaggregation.html#deepseek-multi-node

mooncake需要rdma这种InfiniBand设备支持，nixl不需要

环境准备

1
2
3
4
5
6
7
8
9
10
# 安装Miniconda
wget https://repo.anaconda.com/miniconda/Miniconda3-latest-Linux-x86_64.sh
bash Miniconda3-latest-Linux-x86_64.sh
~/miniconda3/bin/conda init bash
source ~/.bashrc

# 创建虚拟环境
conda create -n sglang python=3.10
conda activate sglang
pip install sglang[all]

服务部署

Prefill服务:

1
2
3
4
5
6
7
8
9
10
#nixl 依赖
#yum install -y ninja-build openssl3
#nixl==0.5.1 Python 3.10.12 Python 3.10.17
#pip install nixl sglang-router
python -m sglang.launch_server \
  --model-path $path \
  --disaggregation-mode prefill \
  --port 30000 \
  --disaggregation-transfer-backend nixl
#--disaggregation-bootstrap-port 默认8998对应路由服务端口

Decode服务:

1
2
3
4
5
6
python -m sglang.launch_server \
  --model-path $path \
  --disaggregation-mode decode \
  --port 30001 \
  --base-gpu-id 1 \
  --disaggregation-transfer-backend nixl

路由服务:
https://docs.sglang.ai/advanced_features/router.html#mode-3-prefill-decode-disaggregation

1
2
3
4
5
6
python -m sglang_router.launch_router \
--pd-disaggregation \
--prefill http://${p}:30000 8998 \
--decode http://127.0.0.1:30001 \
--host 0.0.0.0 \
--port 8000

分布式部署 (2P1D)

Prefill节点配置

节点0:

1
2
3
4
5
6
7
8
9
10
11
export CUDA_VISIBLE_DEVICES=0
python -m sglang.launch_server \
  --model-path $path \
  --disaggregation-transfer-backend nixl \
  --disaggregation-mode prefill \
  --host 0.0.0.0 \
  --port 30000 \
  --dist-init-addr ${prefill_master_ip}:5000 \
  --nnodes 2 \
  --node-rank 0 \
  --tp-size 2

节点1:

1
2
# 修改node-rank参数为1
--node-rank 1

Decode节点配置

1
2
3
4
5
6
7
8
9
10
11
python -m sglang.launch_server \
  --model-path $path \
  --disaggregation-transfer-backend nixl \
  --disaggregation-mode decode \
  --port 30001 \
  --dist-init-addr ${decode_master_ip}:5000 \
  --nnodes 2 \
  --node-rank 0 \
  --tp-size 16 \
  --dp-size 8 \
  --enable-dp-attention
